Koso RX-2 GP Style Multifunction Gauge

• Product Details

  The RX-2 GP Style Multifunction is probably one of Koso's best sellers with its unique color changeable backlight. The illuminated needle with LED pointer makes the RX-2 a very easy meter to read even at night. This instrument features many different functions such as speed, odometer, trip meter, RPM, shift light, temperature, indicator lights and many other functions. Set yourself apart with the RX-2!

  • Speed unit: km/h or MPH.
  • Speedometer range: 0 ~ 360 km/h or 0 ~ 223 MPH.
  • Odometer: 0 ~ 99999.9 km or mile.
  • Trip A / Trip B: 0 ~ 999.9 km or mile.
  • Speeding warning setting range: 30 ~ 180 km/h or 20 ~ 110 MPH, Adjust unit: 5 km/h or 5 MPH.
  • Top speed record: 0 ~ 360 km/h or 0 ~ 223 MPH.
  • Tire circumference setting: 1,000 ~ 2,500 m/m, Adjust unit: 1 m/m, Sensor point: 1 ~ 6.
  • Tachometer range: 0 ~ 15,000, Display unit: 100 RPM.
  • Max RPM record: 0 ~ 15,000 RPM.
  • Stroke / piston setting:
  • 2 stroke: 1, 2, 3, 4, pistons.
  • 4 stroke: 1, 2, 3, 4, 5, 6, 8, 10, 12 pistons.
  • Temperature unit: C or F.
  • Digital water temperature range: 0 ~ 120C or 32 ~ 248F, Display unit: 0.1C or 0.1F.
  • Temperature level display range: 20 ~ 120C or 68 ~ 248F, Display in 10 level, Display unit: 1 level = 10C or 50F.
  • Digital oil temperature range: 0 ~ 120C or 32 ~ 248F, Display unit: 0.1C or 0.1F.
  • Over temperature warning setting (water and oil): 60 ~ 120C or 140 ~ 248F, Adjust unit: 1C or 1F.
  • Top temperature record: 0 ~ 120C or 32 ~ 248F.
  • Fuel gauge: Display in 10 levels, Display unit: 1 level = 10% fuel.
  • Fuel resistance setting: 100 ohm - 510 ohm.
  • Insufficient fuel warning setting: 10 ~ 50%, Adjust unit: 10%.
  • Clock: 24H.
  • Target speed timer: 30 ~ 360 km/h or 20 ~ 220 MPH, Adjust unit: 5 km/h or 5 MPH.
  • Target distance timer: 50 ~ 1,000 m or 1/32 ~ 20/32 mile, Adjust unit: 50 m or 1/32 mile.
  • Top speed timer:
  • The record including:
  • Speed: 0 ~ 360 km/h or 0 ~ 223 MPH.
  • Distance: 0 ~ 999 m or 0 ~ 3,280 feet.
  • RPM: 0 ~ 15,000 RPM.
  • Timer: 0 ~ 59.59.99 second.
  • Indicator light:
  • Neutral (Green).
  • High beam (Blue).
  • Oil (Red).
  • RPM Shift (Light Yellow / Red).
  • Speeding (Red).
  • Turn Signal (Green).
  • Check engine (Amber).

  Report Incorrect Product Information

  ---

  Read More

• Koso RX-2 GP Style Multifunction Gauge Review

• 7 Questions about the Koso RX-2 GP Style Multifunction Gauge

• # Part Numbers for the Koso RX-2 GP Style Multifunction Gauge

  Product Variant	Manufacturer Part #
  Koso RX-2 GP Style Multifunction Gauge	BA010001
