GET RX1 PRO Control Unit

• Product Details

  RX1 PRO BASIC Control Unit with Map Switch.

  GET RX1 PRO BASIC is designed to fully exploit everything your bike has to offer, ensuring better power delivery and timing at any engine speed. All of which translates into smoother riding, more immediate ignition and, above all, greater speed on track. The ECU is complete with two pre-installed racing mappings with which to get the very best out of every standard engine, also with a racing exhaust (sold separately).

  For each of these mappings, the GPA ("Traction Control") technology can be adjusted according to ten different intervention levels via the GET GPA Switch device (sold separately). To achieve maximum performance, the control unit is also compatible with the GET LC-GPA device (sold separately), which, in addition to enabling Traction Control modulation, integrates an electronic Launch Control system to ensure the best possible starting strategy.

  RX1 Pro Basic can be mounted quickly and easily directly onto the bike's main wiring without having to modify the electrical system, as it simply replaces the original ECU. It can quickly process input data coming from the CPS (Cam Position Sensor), TPS (Throttle Position Sensor), MAP (Manifold Absolute Pressure sensor), IAT (Intake Air Temperature sensor) and ECT (Engine Coolant Temperature sensor) and adjust the ignition and carburetion accordingly in all weather conditions and at any altitude.

  Every calibration has been carefully developed for each specific application. The results are approved after intense testing on both the test bench and racetrack by GET engineers, together with the best teams in the MXGP and AMA championships. With RX1 Pro Basic, even less expert users can easily customize the main mapping parameters like carburetion and ignition times in total safety using the app with GET WIFI-COM (sold separately).

  Custom builders who need to work on tuned engines can customize every detail of the mapping using the Maya programming software (sold separately). Maya allows the user to customize injection and ignition times, modify the rev limiter, set the electronic gearing cut-off times and make use of many more professional functions.

  RX1 Pro Basic is also compatible with data acquisition systems like GET SL1 via CAN-BUS, allowing the most demanding technicians to export and process information while developing and preparing the bike.

  Features:

  • Plug-and-play ECU.
  • Integrated Traction Control (GPA technology) and compatible with electronic Launch Control (LC-GPA device; sold separately).
  • Completely programmable via Wi-GET App and MAYA software (sold separately).
  • Two (2) preinstalled racing maps.
  • Notes: Race use ONLY product - NOT intended for street use. The image shown here is for illustrative purposes only and might not fully display the features of the product.

  Technical features:

  • Compatible also with tuned engines: Yes.
  • Compatible with Get Second Injector: No.
  • Compatible with GPA switch: Yes.
  • Compatible with LC GPA: Yes.
  • Compatible with SX1 Connect: Not set.
  • Compatible with SX1 Controller: Not set.
  • Compatible with WiFiCOM: Yes.
  • Data logging compatibility: Yes.
  • GPA switch included: No.
  • Kit Second Injector included: No.
  • LC GPA Included: No.
  • Maps available: 2.
  • Map setting modality: Via WiFiCOM, Via MAYA.
  • SX1 Connect included: Not set.
  • SX1 Controller included: Not set.
  • WiFiCOM included: No.

  Report Incorrect Product Information

  ---

  Read More

• Customer Reviews

• Q&A

• Fitment

• # Part Numbers

  Product Variant

  Manufacturer Part #

  GET RX1 PRO Control Unit

  GK-RX1PRO-0070, GK-RX1PRO-0071, GK-RX1PRO-0072, GK-RX1PRO-0073, GK-RX1PRO-0074, GK-RX1PRO-0075, GK-RX1PRO-0076, GK-RX1PRO-0077, GK-RX1PRO-0078, GK-RX1PRO-0079, GK-RX1PRO-0080, GK-RX1PRO-0081, GK-RX1PRO-0082, GK-RX1PRO-0083, GK-RX1PRO-0084, GK-RX1PRO-0085, GK-RX1PRO-0086, GK-RX1PRO-0087, GK-RX1PRO-0088, GK-RX1PRO-0089, GK-RX1PRO-0090, GK-RX1PRO-0091, GK-RX1PRO-0092, GK-RX1PRO-0093, GK-RX1PRO-0094, GK-RX1PRO-0095, GK-RX1PRO-0096, GK-RX1PRO-0097, GK-RX1PRO-0098, GK-RX1PRO-0099, GK-RX1PRO-0100, GK-RX1PRO-0101, GK-RX1PRO-0102, GK-RX1PRO-0103, GK-RX1PRO-0104, GK-RX1PRO-0105, GK-RX1PRO-0106, GK-RX1PRO-0107, GK-RX1PRO-0108, GK-RX1PRO-0109, GK-RX1PRO-0110
